Plastic Film Recycling Line Instruction:
This series of plastic film recycling line is mainly used to recycle waste PET bottles, PET flakes and PET packaging containers.
The waste Coke bottle PET recycling machine can easily remove labels, caps, rings, glues, dirt and other impurities, and finally you will get the ideal PET flakes.
All your requirements for the recycled waste Coke bottle PET recycling machine will be met.
Film Recycling Line Main Features:
1) This whole recycling line is used to crush, wash, dewater and dry PP, PE Film.
2) The machine takes the advantages of simple structure, easy operation, high capacity, low energy consumption, safety, reliability, etc.
3) This whole production line is automatic controlling, structure arrangement compact, high production efficiency, nice cleanness.
4) Production capacity: 100-3000kg/h.
5) After drying the water content is only 3% (according to the thickness of film).
Film Recycling Line Application:
Film Recycling Line Video:
Film Recycling Line Technical Parameter:
| Name | Motor power (kw) | Dimension (mm) | Water consumption (T/H) | Stainless steel standard (mm) | Electric standard |
|---|---|---|---|---|---|
| Belt conveyor | 2.2 | 4500*690 | – | – | According to customers standard |
| Wet crusher | 75 | – | 2-4 | – | |
| Friction washer | 2.2*2 | 3000*300 | 1-2 | 3-5 | |
| Floating washer | 2.2*2+1.5 | 4500*1300 | 2-4 | 3-5 | |
| Screw conveyor | 2.2 | 2500*250 | 1-2 | 3-5 | |
| High-speed friction washer | 30 | – | 2-4 | 3-5 | |
| Screw converor | 2.2 | 2800*300 | 1-2 | 3-5 | |
| Dewatering machine | 75 | – | – | 5 | |
| Drying system | 36 | – | – | – | |
| Storage hopper for transition | – | – | – | – | |
| Drying system | 36 | – | – | – | |
| Storage hopper | 2.2*2 | – | – | – |
Film Recycling Line Detail:
