This type of PET pelletizing line combines usual pelletizing line with assembled feeding, which highly improves efficiency.
PET pelletizing line combines usual pelletizing line with assembled feeding, which highly improves efficiency. Material will be half-melted and become higher density, then be fed to heating screw. Productivity is highly increased if with parallel double screw compared with usual pelletizing line same screw size. Pellets quality is excellent with low moisture and no bubbles, because of special screw design, vacuum degassing system and strict filtration system. The strand cutting system is our advantage,which can cut material.
If you’re interested, please contact us to know more PET pelletizing machine.
1. Screw and barrel are made of 38CrMoAlA, inlet mouth treated with special alloy: very strong and long life.
2. Easy operation: PET pelletizing machine has automatic constant temperature control and stable performance. After adjusting well, 1 or 2 workers are enough to run this machine, to feed the materials and change pellet receiver.
3. Low cost in using after redesign: now this kind machine is more economic in electric power source and also water. In the long working life of PET pelletizing machine, can save many sources in energy.
4. High output, long operating life and lower noise: it’s the ideal plastic pelletizer machine for nowadays.
| FS series single-stage granulator machine | ||||||
|---|---|---|---|---|---|---|
| Model | Extruder | Screw diameter(mm) | L/D ratio | Power(kw) | Productivity(PE)(kg/h) | Productivity(PP)(kg/h) |
| FSJ70 | 70/33 | φ70 | 33:1 | 110 | 110-150 | 100-130 |
| FSJ85 | 85/33 | φ85 | 33:1 | 150 | 180-250 | 150-200 |
| FSJ100 | 100/33 | φ100 | 33:1 | 210 | 280-350 | 250-300 |
| FSJ130 | 130/33 | φ130 | 33:1 | 300 | 480-550 | 400-480 |
| FSJ160 | 160/33 | φ160 | 33:1 | 370 | 650-750 | 550-650 |
| FSJ180 | 180/33 | φ180 | 33:1 | 460 | 800-1000 | 750-850 |
| FS series double-stage granulator machine | ||||
|---|---|---|---|---|
| Model | FSJ100/120 | FSJ130/130 | FSJ160/160 | FSJ180/200 |
| First extruder parameter | ||||
| Screw diameter(mm) | φ100 | φ130 | φ160 | φ180 |
| L/D ratio | 33 | 33 | 30 | 30 |
| Extruder motor(kw) | 90 | 132 | 185 | 250 |
| Heating power(kw) | 45 | 55 | 70 | 70 |
| Screw speed(RPM) | 0-120 | 0-120 | 0-120 | 0-120 |
| Second extruder parameter | ||||
| Screw diameter(mm) | φ120 | φ130 | φ160 | φ200 |
| L/D ratio | 10-15 | 10-15 | 10-15 | 10-15 |
| Extruder motor(kw) | 30 | 45 | 55 | 75 |
| Heating power(kw) | 30 | 35 | 45 | 60 |
| Screw speed(RPM) | 0-120 | 0-120 | 0-120 | 0-120 |
| Productivity(kg/h) | 250-350 | 400-550 | 500-700 | 800-1000 |
