PET bottle recycling washing line is applied in PET waste bottle or sheet recycling field. PET bottle washing line through crushing, washing and dry process, the waste bottle or sheet will become to be bottle flakes.
PET bottle recycling washing line is applied in PET waste bottle or sheet recycling field. PET bottle washing line through crushing, washing and dry process, the waste bottle or sheet will become to be bottle flakes. The flakes are widely used in plastic industry, like sheet, and profile production.
1. The clean flakes can be used to produce the polyester staple fiber, PET strap band, granules, PET transparent film and sheets,etc. The top class flakes can be used to blow bottles again.
2. PET bottle recycling washing machine can be designed on the basis of how dirty the flakes are, and make sure of the quality of the final products are very clean.
3. PET bottle recycling washing machine output Fangsheng Machinery can supply is from 300kg/h to 2000kg/h.
| Name | Motor power (kw) | Dimension (mm) | Water consumption (T/H) | Stainless steel standard (mm) | Electric standard |
|---|---|---|---|---|---|
| Belt conveyor | 2.2 | 3500*900*3000 | – | – | According to customers standard |
| Label scraping machine | 11 | 2600*1200*1800 | 0.6-1.0 | 3-5 | |
| Manual separating machine | 2.2 | 6000*800*1200 | – | – | |
| Metal detectory | 0.4 | 2200*1200*1500 | – | 3-5 | |
| Belt conveyer | 2.2 | 3500*900*3000 | – | – | |
| Crusher | 37 | 2200*2200*3000 | 0.6-1.0 | – | |
| Screw converor | 3 | 2800*800*2600 | – | 3-5 | |
| High speed friction washer | 30 | 3200*1400*2000 | 1-2 | 3-5 | |
| Screw conveyer | 3 | 2800*800*2600 | – | 3-5 | |
| Floating washer | 3*2 | 5200*1700*2200 | 0.5-1.5 | 3-5 | |
| Screw conveyer | 36 | 2800*800*2600 | – | 3-5 | |
| Steam washer | 7.5 | 1800*1800*2700 | 0.5-1.5 | 3-5 | |
| Screw conveyer | 3 | 2800*800*2600 | – | 3-5 | |
| Floating washer | 3*2 | 5200*1700*2200 | 0.5-1.5 | 3-5 | |
| Screw conveyer | 3 | 2800*800*2600 | – | 3-5 | |
| Dewatering machine | 5.5 | 800*2200*2200 | – | 5 | |
| Drying system | 11 | 3500*2200*2200 | – | 3-5 | |
| Label separater | 4 | 800*1100*3800 | – | – | |
| Storage hopper | – | 1500*1500*3800 | – | – | |
| Electric elements | – | 2000*450*1780 | – | – |
