Fangsheng Machinery is a professional manufacturer and supplier of waste plastic recycling washing line and plastic granulator machine. 7x24 hours all day waiting for your inquiry!
Fangsheng Machinery is a professional manufacturer and supplier of HDPE milk bottle washing line. High quality, stable performance.
The HDPE Bottle recycle is always a difficulty in plastic recycling field. The film is not easy in washing and nadapted de-watering, while through constant research and practice, we have solved these problems. This HDPE milk bottle washing line has adapter the character of bottle adequately and has made a pertinent scheme. After selection, wet crushing, friction washing and etc procedures, the dust, oil on the bottle can be completely cleaned. The recycled products are being widely used in granulation, injection and other fields.
1.Final products has good quality. When process HDPE bottle, final products humidity below 1%, impurities100ppm,PVC label content 100ppm . The HDPE bottle washing line capacity between 300kg/h-2000kg/hour.
2.Parts which contact material use SUS304 stainless steel, thickness more than 3mm, ensure long service lift time.
3.World famous brand components applied on the HDPE bottle washing production line- e.g. SKF bearing, Siemens contactor, Omron temperature, FUJI invertor, Siemens PLC controller, etc.
4.The HDPE bottle washing line with CE certification, ISO9001 certification.
| Name | Motor power (kw) | Dimension (mm) | Water consumption (T/H) | Stainless steel standard (mm) | Electric standard |
|---|---|---|---|---|---|
| Belt conveyor | 2.2 | 3500*900*3000 | – | – | According to customers standard |
| Label scraping machine | 11 | 2600*1200*1800 | 0.6-1.0 | 3-5 | |
| Manual separating machine | 2.2 | 6000*800*1200 | – | – | |
| Metal detectory | 0.4 | 2200*1200*1500 | – | 3-5 | |
| Belt conveyer | 2.2 | 3500*900*3000 | – | – | |
| Crusher | 37 | 2200*2200*3000 | 0.6-1.0 | – | |
| Screw converor | 3 | 2800*800*2600 | – | 3-5 | |
| High speed friction washer | 30 | 3200*1400*2000 | 1-2 | 3-5 | |
| Screw conveyer | 3 | 2800*800*2600 | – | 3-5 | |
| Floating washer | 3*2 | 5200*1700*2200 | 0.5-1.5 | 3-5 | |
| Screw conveyer | 36 | 2800*800*2600 | – | 3-5 | |
| Steam washer | 7.5 | 1800*1800*2700 | 0.5-1.5 | 3-5 | |
| Screw conveyer | 3 | 2800*800*2600 | – | 3-5 | |
| Floating washer | 3*2 | 5200*1700*2200 | 0.5-1.5 | 3-5 | |
| Screw conveyer | 3 | 2800*800*2600 | – | 3-5 | |
| Dewatering machine | 5.5 | 800*2200*2200 | – | 5 | |
| Drying system | 11 | 3500*2200*2200 | – | 3-5 | |
| Label separater | 4 | 800*1100*3800 | – | – | |
| Storage hopper | – | 1500*1500*3800 | – | – | |
| Electric elements | – | 2000*450*1780 | – | – |
